420/90R30 Titan Farm AgraEDGE R-1W 142D 95%
Stock Number:
NTS-134363
USED
TIRE
Availability
SOLD
Shipping & Delivery
Nationwide shipping is available for this item.
Due to the nature of LTL shipments, delivery by the estimated date is not guaranteed. NTS Tire Supply is not responsible for delays in transit.
Conditions
| Condition Notes | |
| Condition |
Grade
A
GRADE ATires & Tracks - In very good condition with a clean casing, no repairs, no damage and no weathering.NOTE: Tread remaining does not affect the product’s Condition grade. Wheels & Hardware - Product is like new with no noticeable repairs or damage. Refurbished products may be Grade A.
GRADE BTire & Tracks - In average condition with some possible weathering. Expect normal wear and tear and/or minor repairs.Wheels & Hardware - In average condition with some possible fading, scratches, light rust and/or minor repairs.
GRADE CTire & Tracks - Usable but in poor condition. Likely to have moderate to heavy stubble, weathering and/or repairs.Wheels & Hardware - Usable but in poor condition. Likely to have poor paint, moderate to heavy rust, and noticeable damage and/or repairs. |
| Tread Depth Remaining | 95% |
| Chips/Chunking/Cuts | Light |
| Road Wear | |
| Weathering/Dry Rot | |
| Stubble | |
| Bead Damage/Bent/Chipped | |
| Blistering-SW/Liner or Face | |
| Casing Cracks | |
| Repairs Completed | None |
| Warranty | 2 Year Black Gold Warranty |
| Mfg Date Code | 2022 |
| Required Product | None |
Specifications
Agricultural Radial R-1W Rear Tractor tire Suitable for Moist to Wet Soil Service.
- Modern lug angle design
- New construction in the sidewall and lug angle
- Row crop through flotation sizes
- Provides optimum self-cleaning and traction
- Provides excellent roading capability
- For greater deflection and improved footprint resulting in less soil compaction
| Stock No. | NTS-134363 |
| Brand | Titan Farm |
| Model/Style | AgraEDGE |
| Tread Style | (R-1W) Agricultural Deep Tread/Wet Soil |
| Tire Size | 420/90R30 |
| Rim Width | 15" |
| Preferred Rim | |
| RCI Group | 42 (57.81" - 61.00") |
| Casing Technology | |
| Casing Application | |
| Tire Compound | |
| Belt Construction | |
| Sidewall Style | |
| TT/TL | (TL) Tubeless |
| Weight | 261.0 |
| Diameter | 59.32 |
| Width | 17.4 |
| Rolling Circumference | 0.0 |
| Static Load Radius | 26.7 |
| Flat Plate Area | 0 |
| Tread Width | 0.0 |
| Ply Rating | |
| Load Index/Speed Rating | 142D |
| Load Limit Single | 5840 lbs / 2649 kgs |
| Load Limit Dual | 5139 lbs / 2331 kgs |
| Load Limit Triple | 4788 lbs / 2171 kgs |
| Max PSI | 23 |
