480/80R50 Titan Farm AG49M Radial R-1W 159B 50%
Stock Number:
A000285
USED
TIRE
Availability
SOLD
Shipping & Delivery
Nationwide shipping is available for this item.
Due to the nature of LTL shipments, delivery by the estimated date is not guaranteed. NTS Tire Supply is not responsible for delays in transit.
Conditions
| Condition Notes | |
| Condition |
Grade
C
GRADE ATires & Tracks - In very good condition with a clean casing, no repairs, no damage and no weathering.NOTE: Tread remaining does not affect the product’s Condition grade. Wheels & Hardware - Product is like new with no noticeable repairs or damage. Refurbished products may be Grade A.
GRADE BTire & Tracks - In average condition with some possible weathering. Expect normal wear and tear and/or minor repairs.Wheels & Hardware - In average condition with some possible fading, scratches, light rust and/or minor repairs.
GRADE CTire & Tracks - Usable but in poor condition. Likely to have moderate to heavy stubble, weathering and/or repairs.Wheels & Hardware - Usable but in poor condition. Likely to have poor paint, moderate to heavy rust, and noticeable damage and/or repairs. |
| Tread Depth Remaining | 50% |
| Chips/Chunking/Cuts | Moderate |
| Road Wear | Moderate |
| Weathering/Dry Rot | None |
| Stubble | Heavy |
| Bead Damage/Bent/Chipped | None |
| Blistering-SW/Liner or Face | None |
| Casing Cracks | Light |
| Repairs Completed | None |
| Warranty | 2 Year Black Gold Warranty |
| Mfg Date Code | 3804 |
| Required Product | None |
Specifications
Agricultural R-1W Rear Tractor Drive tire with Deep Tread Suitable for Moist to Wet Soil Conditions.
- Wide base and wider section width
- Greater flotation, improved traction and smoother ride
- Allow for higher loads
| Stock No. | A000285 |
| Brand | Titan Farm |
| Model/Style | AG49M Radial |
| Tread Style | (R-1W) Agricultural Deep Tread/Wet Soil |
| Tire Size | 480/80R50 |
| Rim Width | 15" |
| Preferred Rim | |
| RCI Group | 48 (79.31" - 83.65") |
| Casing Technology | |
| Casing Application | |
| Tire Compound | |
| Belt Construction | |
| Sidewall Style | |
| TT/TL | (TL) Tubeless |
| Weight | 526.46 |
| Diameter | 80.2 |
| Width | 18.9 |
| Rolling Circumference | 0.0 |
| Static Load Radius | 37.2 |
| Flat Plate Area | 0 |
| Tread Width | 0.0 |
| Ply Rating | |
| Load Index/Speed Rating | 159B |
| Load Limit Single | 9650 lbs / 4377 kgs |
| Load Limit Dual | 8492 lbs / 3851 kgs |
| Load Limit Triple | 7913 lbs / 3589 kgs |
| Max PSI | 35 |
