9.75"W x 16.5"D, Kubota Orange 8-Hole Skid Steer
Stock Number:
64251
NEW
WHEEL
Availability
Call for Availability
Shipping & Delivery
Nationwide shipping is available for this item.
Due to the nature of LTL shipments, delivery by the estimated date is not guaranteed. NTS Tire Supply is not responsible for delays in transit.
Specifications
| Stock No. | 64251 |
| Brand | Wold Wheel |
| Model/Style | Skid Steer |
| Rim Design | |
| Rim Diameter | 16.5" |
| Rim Width | 9.75" |
| Paint Color | Kubota Orange |
| Weight Holes | No |
| Flange Reinforcement | No |
| Valve Guard | No |
| Valve Hole Location | |
| Weight | 40.0 |
| Diameter | 19.0 |
| Width | 11.25 |
| Disc Thickness | 0.0 |
| Wheel Offset | 0.0 |
| Rim Backside | 0.0 |
| Rim Frontside | 3.625 |
| Rim Inside Diameter | 0.0 |
| Drop Center Width | |
| Casting Diameter | 0.0 |
| Rim Material Thickness | 0.0 |
| Valve Hole Diameter | |
| Bolt Hole Quantity | 8 |
| Bolt Circle Diameter | 10.75 |
| Bolt Hole Size | 16MM(5/8") Stud |
| Actual Bolt Hole Size | 0.688 |
| Pilot Hole | 8.75 |
| Bolt Countersink | 90 Degree Conical |
| BtB Measurement | 0.0 |
| Lugs/Rails Quantity | |
| Outside Bolt Hole Quantity | 0 |
| Outside Bolt Circle Diameter | 0.0 |
| Outside Bolt Hole Size | |
| Outside Actual Bolt Hole Size | 0.0 |
| Outside Bolt Countersink | |
| Outside BtB Measurement | 0.0 |
| Max Weight | 6000.0 |
| Rim Rating |
