215/75R17.5 Hercules H-902 ST H (16 Ply), 133L 100%
Stock Number:
59545(SIS)
NEW
TIRE
Availability
Not Available
Shipping & Delivery
Nationwide shipping is available for this item.
Due to the nature of LTL shipments, delivery by the estimated date is not guaranteed. NTS Tire Supply is not responsible for delays in transit.
Specifications
Commercial Truck/Bus. Medium-Duty Truck Highway All-Position Rib tire for Both Steer and Trailer Application.
- Wide 5-rib design
- Designed with lower rolling resistance
- Delivers long mileage and shoulder wear resistance on steer axle use
- To provide better fuel efficiency
| Stock No. | 59545(SIS) |
| Brand | Hercules |
| Model/Style | H-902 |
| Tread Style | (ST) Trailer Tire |
| Tire Size | 215/75R17.5 |
| Rim Width | 6.5", 6.75", 6" |
| Preferred Rim | |
| RCI Group | 29 (29.36" - 31.00") |
| Casing Technology | |
| Casing Application | |
| Tire Compound | |
| Belt Construction | |
| Sidewall Style | |
| TT/TL | (TL) Tubeless |
| Weight | 60.0 |
| Diameter | 30.39 |
| Width | 8.0 |
| Rolling Circumference | 0.0 |
| Static Load Radius | 0.0 |
| Flat Plate Area | 0 |
| Tread Width | 0.0 |
| Ply Rating | H (16 Ply) |
| Load Index/Speed Rating | 133L |
| Load Limit Single | 4540 lbs / 2059 kgs |
| Load Limit Dual | 3995 lbs / 1812 kgs |
| Load Limit Triple | 3722 lbs / 1688 kgs |
| Max PSI | 124 |
