500/60-22.5 Mitas TR-12 I-3 170A8 100%
Stock Number:
1014111030000
NEW
TIRE
Availability
Not Available
Shipping & Delivery
Nationwide shipping is available for this item.
Due to the nature of LTL shipments, delivery by the estimated date is not guaranteed. NTS Tire Supply is not responsible for delays in transit.
Specifications
Traction tires for wide agricultural application
- Pattern with excellent traction
- developed for powered wheels of agricultural and industrial machinery.
- Applicable for trailed wheels as well.
| Stock No. | 1014111030000 |
| Brand | Mitas |
| Model/Style | TR-12 |
| Tread Style | (I-3) Agricultural Implement Traction Tread |
| Tire Size | 500/60-22.5 |
| Rim Width | 16" |
| Preferred Rim | |
| RCI Group | 38 (46.96" - 49.65") |
| Casing Technology | |
| Casing Application | |
| Tire Compound | |
| Belt Construction | |
| Sidewall Style | |
| TT/TL | (TL) Tubeless |
| Weight | 197.0 |
| Diameter | 47.0 |
| Width | 19.8 |
| Rolling Circumference | 0.0 |
| Static Load Radius | 20.4 |
| Flat Plate Area | 0 |
| Tread Width | 0.0 |
| Ply Rating | |
| Load Index/Speed Rating | 170A8 |
| Load Limit Single | 13200 lbs / 5987 kgs |
| Load Limit Dual | 11616 lbs / 5268 kgs |
| Load Limit Triple | 10824 lbs / 4909 kgs |
| Max PSI | 65 |
